96
SPECIFICATIONS
MAIN TRUCK - 1H2
Model code
Item
1H2
SRX35N SRX45N SRX45LN
Rated Load Capacity lb (kg) Refer to Truck Data Plate
Load center in (mm) 24 (610)
Overall Length (to face of forks) in (mm) 54.1 (1375) 55.6 (1415) 60.1 (1525)
Overall Width (standard tires) in (mm) 43.0 (1090)
Wheelbase in (mm) 59.0 (1500) 60.1 (1525) 64.6 (1640)
Tire Size Drive tire in (mm) 13 x 5.5 (330 x 140)
Caster wheels - dual in (mm) 7 x 2.87 (178 x 73)
Load wheels - tandem in (mm) 5 x 4 (127 x 100)
Minimum Turning Radius Outside in (mm) 69.4 (1762) 70.4 (1790) 74.9 (1900)
Minimum Right Angle Stack Add load length &
clearance
in (mm) 100 (2540) 102 (2590) 106 (2690)
Fork Length (standard) in (mm) 42 (1070)
Fork Width x Thickness in (mm) 4 x 1.5 (100 x 40) 4 x 1.75 (100 x 45) 4 x 1.75 (100 x 45)
Ground Clearance
Under Mast in (mm) 2.0 (50)
Under Frame, center
of wheelbase
in (mm)
2.0 (50)
