If the new address is out of the
specified range, button is
ignored. Otherwise a command
screen appears where you shall
confirm the readdressing:
The following information is
displayed on the screen:
 The new address that will be
assigned to the device;
 The text message specified
for this address;
 Message Different device ID
– only when the ID number of
the device is different than
the number for this address
saved in the control panel;
 Message Different device type – only when the device type is different than the type saved for
this addres in the control panel;
 Message Different device class – only when the temperature class of the device is different
than the class saved in the control panel.
When you press button the readdressing is cancelled and the screen for selection of new
address is reverted.
When you press button the readdressing is completed and the screen for selection of
devices that shall be excluded from the service zone is reverted (or the screen with the message The
service zone is empty).
13.7.4. Menu Exclude devices
The menu allows the user to
exclude or include separate
addressable devices:
All 250 (125 in each loop)
addressable devices are accessible
whether included physically to the
fire alarm loops or not. In the middle
of the heading is displayed the total
number of devices included in both
loops.
For each device is displayed:
 Its consecutive number, the
loop it is included in and its
address in the loop – in the
top line;
 The text message – in the
line beneath.
The devices obtain numbers according to the sequence:
 Devices in Loop 1 – numbers from 1 tо 125;
 Devices in Loop 2 – numbers from 126 tо 250.
The selected device is pointed by arrow – „>>”.
When you press a digit button, the Go to field is activated and you can enter a random 3-digit
number for the device. To edit the number, press button and the last entered digit will be deleted.
С
Mode:DAY LOC 18:13:51 Fri 26 Mar 2010
Readdressing Lp1 Аddr2
New address:3
Point 1.003
Different Device ID
Different Device Type
Differenet Device Class
Save new Data?
– confirm
– cancel
Mode:DAY LOC 9:49:43 Mon 29 Mar 2010
Exclude Devices Devices total: 63 Go to:
>> 1 Lp1 Аddr1 On
Point 1.001
2 Lp1 Аddr2 On
Point 1.002
3 Lp1 Аddr3 Off
Point 1.003
4 Lp1 Аddr4 On
Point 1.004
5 Lp1 Аddr5 On
Point 1.005
6 Lp1 Аddr6 Off
Point 1.006
0
1
2
3
4
5
6
7
8
9
С
