UniPOS IFS7002 two signal loops
Instruction Manual Page 8
Revision 11/01.17 Of 145
maximum of 125 devices (addressable fire detectors and/or addressable executive devices) can be
integrated into each loop.
FIRE CONDITION STAGE I phase 1 of Fire condition; upon activation of automatic fire detector
the fire control panel enters Fire condition until the specified time expires. The common and local light
indicators, local sound signaling and a text message displayed on the LCD display indicate the phase.
FIRE CONDITION STAGE II phase 2 of Fire condition; the fire control panel enters Fire
condition stage II when: a) the time for Fire condition stage I has expired or b) upon activation of a
manual call point. The common light indicators, local sound signaling and a text message displayed
on the LCD display indicate the phase.
INTERRUPTED LOOP OR MONITORED OUTPUT non-fatal fault condition due to current
value in a loop or in monitored output lower than the threshold value. The user shall define the
threshold value separately for each loop.
COINCIDENCE MODE mode of operation of the fire alarm zones, that requires activation of at
least two automatic fire detectors in a zone so the fire control panel is able to enter Fire condition,
phase Fire condition stage I, in this particular zone (see section 6.3).
RELAY OUTPUT a relay, potential-free switching outputs provided for controlling external
executive devices.
POWER LOOP a two-wire connection supplying power to addressable executive devices in
case their consumption exceeds the load carrying capacity of the fire alarm loops, which they have
been integrated into. IFS7002 has 1 power loop, its load carrying capacity is 1000 mA.
SYSTEM ERROR fatal fault condition due to a fault in system’s basic component
SYSTEM OPERATION the fire control panel executes internal operations to set its registers.
This is visualized on the LCD display with a text message for system operations, before the user is
allowed to proceed with his work with IFS7002.
DEVICE REMOVED non-fatal fault condition due to removed device (addressable fire detector
of a specific zone and/or addressable executive device).
FATAL FAULT CONDITION fault condition that prevents the fire control panel from continuing
its operation. The indication is common light indication, local sound indication and text messages on
the LCD display.
3. Function
Interactive Fire Control Panel IFS7002 is designed to operate with addressable automatic fire
detectors and manual call points. It controls addressable executive devices integrated into fire alarm
loops. The addressable executive devices can be power supplied from the fire alarm loop or from a
power loop. The panel has outputs provided for integration of external executive devices.
4. Technical data
4.1. Physical configuration
2 fire alarm loops
1 power loop
2 monitored outputs
2 relay outputs for fire condition
1 relay output for fault conditions
4.2. Fire alarm zones
Maximum number of zones - 250
Maximum number of fire detectors in a zone - 60
4.3. Fire alarm loops
