UniPOS IFS7002 User Manual

UniPOS IFS7002 two signal loops
Instruction Manual Page 87
Revision 11/01.17 Of 145
13.5.3. Menu Zone parameters
The menu is provided for zone
parameters set up:
 Manual call point priority –
when the manual call points
have priority, their response
will trigger Fire condition
phase 2 in the zone; if they
do not have priority, their
response will trigger Fire
condition phase 1 in the
zone; i.e. they will be treated
as automatic fire detectors;
 Coincidence mode – when
set to this mode, the zone will
enter Fire condition phase 1 if
at least 2 low priority fire
detectors are activated;
 Time Fire Phase 1 – Phase 2 – the delay time before the control panel proceeds from fire
condition stage I to fire condition stage II in the zone;
 Inspection time – period of time that, when you press button , will be added to the
remaining time for transition from Fire condition stage I to Fire condition stage II in a zone.
To edit parameters Manual call point priority and Coincidence Mode use button – by
pressing the button you can change the value of the parameter alternatively form Yes to No and vise
versa.
To edit parameters Time Fire Phase 1 – Phase 2 and Inspection time use the digit buttons. When
you press button the digit at the left side of the cursor will be deleted. If the values for Time Fire
Phase 1 – Phase 2 and Inspection time are higher than 255, they will be automatically replaced by
255 as soon as the last digit is entered.
С
Mode: DAY LOC 15:41:44 Thu 25 Mar 2010
SetUp Zone 1 Zone parameters
Manual call point Priority: Yes
Coincidence Mode: No
Time Fire Phase 1 – Phase 2: 120 s
Inspection time: 120 s
0
1
2
3
4
5
6
7
8
9
С

UniPOS IFS7002 Specifications

General

Monitored inputs	8
Battery voltage	24V DC
Display	LCD
Touch Screen	No
Processor	ARM Cortex-M3
Operating Temperature	-10°C to +55°C
Operating System	Proprietary
Memory	512KB Flash
Communication Interfaces	RS485, Ethernet, USB
