UniPOS IFS7002 User Manual

UniPOS IFS7002 two signal loops
Instruction Manual Page 31
Revision 11/01.17 Of 145
 Text message for the device – for addressable output devices only.
Buttons and situated in the right panel section scroll the pages up and down and allow
displaying next page or previous page. Each page contains 5 messages for disables. Button
appears on the screen if next page is available; button appears on the screen if previous page is
available.
12.2.3. Menu Zones in Test
The menu is provides detailed information for zones set to Test Mode.
Menu Zones in Test contains the following subordinate menus:
 Menu Zones – brings out information for zones set to Test Mode;
 Меню Zone Status – brings out information for the status of zones set to Test Mode.
12.2.3.1. Menu Zones
If no zones are set to Test Mode
the following screen appears:
Where zones set to Test Mode are
available, the following screen
appears:
The displayed information is for
 Zone number;
 Text message for the zone
Buttons and in the right
panel section scroll the pages up and
down and allow displaying next page
or previous page. Each page
contains 5 messages for zones in
Test Mode. Button appears on
the screen if following page is
available; button appears on the
screen if previous page is available.
Mode:DAY LOC ActInp 0000 10:10:07 Mon 08 Mar 2010
FIRE CONTROL PANEL IFS7002
UniPOS
List/Test/Zones
NO ZONES IN TEST
Mode:DAY LOC ActInp 0000 10:59:27 Mon 08 Mar 2010
FIRE CONTROL PANEL IFS7002
UniPOS
List/Test/Zones
006
001 Zone 001
Zone 001
002 Zone 002
Zone 002
003 Zone 003
Zone 003
004 Zone 004
Zone 004
005 Zone 005
Zone 005
