12.2.6. Screen Panel configuration
The screen displays information
associated with:
 The fire control panel local
network; the possible
conditions are none, On or
Off;
 Periphery devices; their
possible conditions are none,
On or Off;
 The power supply loop; its
possible conditions are none,
On or Off;
 The language of the text
messages.
 Earth check; its possible
conditions On or Off.
In the right part of the first row is
displayed the software version of the
Fire Control Panel for example
v16.10.10;
12.2.7. Menu Panel parameters
It is used when the fire control panel is connected in a global network or a local network with other
fire control panels.
The menu has two sub-menus:
 Menu Global Network
 Menu Local Network
12.2.7.1. Menu Network
It displays information about
RS232-network parameters:
 Rate [bits/s]-data exchange rate
 Address in the network
 Connection via modem –
onformation if the
communication is done via
information, the screen displays
“Yes” or “No”, respectively
Telephone number – it is
possible four 15-digit telephone
numbers to be entered as the letter P
– for pulse dialling and the letter T –
for tonal dialling are entered before
the respective number
12.2.7.2. Menu Local Network
It displays information for the connection of the fire control panel in a local network with other fire
control panels or repeaters, which is discussed in details in Appendix Interactive Fire Control Panel –
Local Network Operation.
12.2.8. Menu Loops
The menu displays information for the loops and the devices integrated in the loops. It contains
two identically organized submenus – for Loop 1 and for Loop 2; each submenu contains:
 Screen Loop parameters;
Mode:DAY LOC АctInp 0000 11:23:10 Tue 11 Mar2010
FIRE CONTROL PANEL IFS7002
UniPOS
Panel configuration v16.10.08
Local network: On
Periphery Module 1: none
Periphery Module 2: none
Periphery Module 3: none
Power loop: On
Language: English
Earth check: On
Mode:DAY LOC АctInp 0000 16:37:10 Tue 11 Mar 2010
FIRE CONTROL PANEL IFS7002
UniPOS
RS network parameters
Bit rate,[Bits/s]: 2400
Network address: 1234
Modem connection: No
Phone number 1: P11
Phone number 2: T22
Phone number 3: P33
Phone number 4: P44
