 LED status – Off (not illuminated/ not flashing) or On (illuminated);
 Information for fault condition – the text message Fault appears only if the module
detected a fault condition
 For Input/Output modules type FD7203OC and FD7203R:
 Status of device’s output – On or Off;
 Status of device’s isolator in the power loop– Off (not activated) or On (activated);
 Status of device’s isolator – Off (not activated) or On (activated);
 Status of the LED – Off (not emitting light/not flashing) or On (emitting light/flashing);
 Information for fault condition – a text message Fault is displayed only in case the
module has registered a fault;
 For single output modules FD7204S:
 Status of the output – On or Off;
 Status of the isolator of the module at the power supply loop – Off (no response) or On
(responded);
 Status of the isolator of the module – Off (no response) or On (responded)
 LED status – Off (not illuminated/ not flashing) or On (illuminated)
 Information for fault condition – the text message Fault appears only if the module
detected a fault condition.
 For single output modules FD7204:
 Status of the output – On or Off;
 Status of battery;
 Status of the isolator of the module – Off (no response) or On (responded)
 LED status – Off (not illuminated/ not flashing) or On (illuminated)
 Information for fault condition – the text message Fault appears only if the module
detected a fault condition.
 For input/output modules FD7203 (1 input/1 output) and FD7203 (10 inputs/16 outputs):
 Outputs switched on – a list of switched on outputs or the text message None appears
if no outputs are switched on;
 Device’s activated inputs – a list of activated inputs or a text message None, if no
inputs have been switched on;
 Status of the isolator of the module at the power supply loop – Off (no response) or On
(responded);
 Status of the isolator of the module – Off (no response) or On (responded);
 LED status – Off (not illuminated/ not flashing) or On (illuminated);
 Information for fault condition – break or short circuit
12.2.11. Menu Inputs
The menu displays information for addressable inputs parameters. When you enter the menu the
following screens are displayed:
 Where addressable input devices are not available – a screen with the message No Outputs
appears; the only option is to exit the menu;
