UniPOS IFS7002 User Manual

UniPOS IFS7002 two signal loops
Instruction Manual Page 43
Revision 11/01.17 Of 145
 LED status – Off (not illuminated/ not flashing) or On (illuminated);
 Information for the level of detector contamination– the text message Contaminated
appears only if the fire detector is contaminated and needs cleaning;
 Information for Fire condition – the text message Fire Alarm appears only when the
detector responded;
 Information for Pre-alarm – the text message PreAlarm appears only if the smoke
concentration value is near the response threshold for fire condition;
 Information for Fault condition – the text message Fault is displayed only when the fire
detector responded to a fault condition;
 For conventional line-monitoring modules with heat detector FD7201:
 The current value measured in the conventional fire alarm line, connected with the
module;
 Information for fire condition in the conventional line – the text message Fire Alarm
appears only when a detector in the conventional line responded;
 Information for short circuit in the conventional line – the text message Short appears
only if short circuit is detected in the conventional line;
 Information for fault condition: break in the conventional line – the text message Open
appears only if a break in the conventional line is detected;
 Information for fault condition: removed fire detector in the conventional line – the text
message Removed FD appears only when a conventional line detector is removed;
 The temperature in the module, measured by the fire detector, in Celsius;
 Temperature class of the detector in the module;
 Status of the detector’s isolator – Off (no response) or On (responded)
 LED status – Off (not illuminated/ not flashing) or On (illuminated);
 Information for Fire condition – the text message Fire Alarm appears only when the
heat detector in the conventional line-monitoring module responded or when a fire
detector in the conventional line responded;
 Information for fault condition – the text message Fault appears only if the
conventional line-monitoring module detected a fault condition;
 For adapters type FD7201S:
 The current value measured in the conventional line, connected to the adapter;
 Information for Fire condition in the conventional line – a text message Fire is displayed
only in case a fire detector has been activated in the conventional line;
 Information for fault condition – Short circuit in conventional line – a text message Short is
displayed only in case a short circuit has been detected in the conventional line;
 Information for fault condition – Break in conventional line – a text message Break is
displayed only when the conventional line has been cut off;
 Information for fault condition – Removed device in conventional line – a text message
Removed FD is displayed only in case a device has been removed from the conventional
line;
 Status of the adapter’s isolator– Off (not activated) or On (activated);
 Status of the LED – Off (not emitting light/not flashing) or On (emitting light/flashing);
 Information for Fire condition – a text message Fire is displayed only in case a fire
detectors has been activated in the conventional line;
 Information for fault condition – a text message Fault is displayed only in case the adapter
has registered a fault;
 For input/output modules FD7203 (3 inputs/5 outputs):
 Outputs switched on – a list of switched on outputs, designated „Rel1” to „Rel5”, or the
text message None appears if no outputs are switched on;
 Device’s activated inputs – a list of activated inputs, designated as „In1” tо „In3”, or a
text message None, if no outputs have been switched on;
 Input status – „0” (no input signal) or„1” (input signal);
 Status of the isolator of the module at the power supply loop – Off (no response) or On
(responded);
 Status of the isolator of the module – Off (no response) or On (responded);
