UniPOS IFS7002 two signal loops
Instruction Manual Page 88
Revision 11/01.17 Of 145
13.5.4. Menu Service Rem. Zones
The menu allows the user to specify the serviced remote control panels in the zone (see Interactive
Fire Control Panel IFS7002 – Local Network Operation).
13.5.5. Screen Text message
The screen allows the user to insert and edit a text message for a zone. Upon activation of the
screen a check up is being run for included external keyboard.
13.5.5.1. Built-in keypad
If no external keyboard is
included to the control panel, then
the following screen appears:
To edit the text use the buttons
having symbols – when you press a
button, the symbol appears over the
position of the cursor, and the
previous text is moved one position
to the right. The cursor remains for 1
s over the same position; if you press
it again, the symbol will be changed
by the next one marked on the button
(the symbol Ω marked on the second
button means that the figure 1 is in
combination with punctuation marks).
1 s after the last pressing the cursor
moves to the next position to the
right. If you press another button
during this 1 second, the cursor first moves one position to the right and then the new symbol is
inserted. The maximum length of the message is 40 symbols. If you press a button after a 40-symbol
message is already entered, the text will not be accepted and the symbol will not be inserted (the
cursor moves one position to the right if the end of the text message is not reached yet).
Press button to delete:
The symbol under the cursor, if any;
The symbol to the left of the cursor, if there is no symbol under it.
Press button or to move the cursor one position to the left or to the right.
Button changes the case from lowercase to uppercase, button changes the
uppercase to lowercase.
Button changes the Latin font to Cyrillic font, button changes the Cyrillic font to
Latin font.
Mode:DAY LOC 15:51:54 Thu 25 Mar 2010
SetUp Zone 1 Text message
