UniPOS IFS7002 User Manual

UniPOS IFS7002 two signal loops
Instruction Manual Page 9
Revision 11/01.17 Of 145
 Maximum number of fire detectors in a loop - 125
 Connecting line - two-wire shielded
 Maximum resistance of a loop - 100
 Output resistance of a loop - 20
 Maximum consumption of a loop - 120mA
4.4. Power loop
 Connecting line - two-wire
 Maximum resistance of the loop - 10
 Output resistance of the loop - 2
 Maximum consumption of the loop - 1A
4.5. Monitored outputs
 Type - potential
 Еlectrical characteristics - (24±5)V/1A
4.6. Relay outputs for fire conditions
 Type - potential free, switching,
 Electrical characteristics - 3A/125VAC; 3A/30VDC
4.7. Relay output for fault conditions
 Type - potential free, switching
 Electrical characteristics - 3A/125VAC; 3A/30VDC
4.8. Performance
 Control over fire alarm loops and monitored outputs for fault conditions (short circuit
and interruption) and automatic reset
 Detection of removed devices in the loops and automatic reset
 Ability to set the zones in Coincidence Mode
 Two phases of Fire condition, programmable time for Fire condition stage I,
separately for each zone
 Option to prolong the time period for Fire condition stage I with programmable
inspection period, specified for each zone
 Built-in sounder for fire condition – one tonal, discontinuous, can be switched off
 Built-in sounder for fault condition – one tonal, discontinuous, can be switched off
 Built-in real time clock
 Set of test modes and options for adjustment:
 Setting the clock;
 Check ups on light and sound indications;
 Test of fire alarm zones;
 Adjustment of outputs and integrated external devices;
 Programming of parameters and modes of operation;
 Remote programming of the parameters from distant operator control point;
 Energy independent archive of registered events with the events type, date and hour
– up to 1023 events;
 Interfaces for communication with external devices - CAN 2.0B and RS-232
(directly or via modem).
4.9. Indications of registered events
 Light indication - LED
 Text messages - LCD display,
320 х 240 points, backlit
 Sound signaling - built-in sounder
4.10. Power supply
4.10.1. Mains
 voltage - 220/230V
 frequency - 50Hz
4.10.2. Back up batteries
 battery type - lead, gel electrolyte
 number of batteries - 2 pcs
 connection - serial connection
