UniPOS IFS7002 User Manual

UniPOS IFS7002 two signal loops
Instruction Manual Page 62
Revision 11/01.17 Of 145
The menu has the following
layout:
The information for the first
active parameter is displayed in
inversive colours (white letters on
black background). Buttons and
at the right panel side allow the
user to move between the active
parameters only.
To edit the parameters use
button – each time you press
it the parameter value changes to the
next acceptable value.
13.3. Menu Panel parameters
Use the menu when the control panel is integrated into a local network of panels (see Interactive
Fire Control Panel IFS7002 – Operation in Local Network).
13.4. Menu Loops
The menu is provided for set up of fire alarm loops and devices integrated in the loops. It contains
two submenus of identical layout – for Loop 1 and for Loop 2. Each submenu contains:
 Menu Loop parameters;
 Screen List devices
 Menu Device parameters;
 Function Check up;
 Function Manual addressing.
13.4.1. Menu Loop parameters
The menu allows the user to
adjust the parameters of the fire
alarm loop:
 Loop status - On or Off
 Number of devices integrated
in the loop;
 Addressing of the devices in
the loop – Automated or
Manual.
To correct Status and Addressing
parameters, use button –
when pressed, the parameter value
changes alternatively:
- for Status parameter – from
position On to position Off and vice
versa;
- for Addressing parameter –
from position Automated to Manual and vice versa.
Mode: DAY 12:51:18 Tue 23 Mar 2010
Panel configuration
Local Network: on
Periphery Module 1: none
Periphery Module 2: none
Periphery Module 3: none
Power loop: On
Language: English
Check Earth: On
Mode: DAY LOC 14:18:38 Tue 23 Mar 2010
Set Up Loop 1
Status: On
Number of Devices (0 – 125): 37
Addressing: Automated
0
1
2
3
4
5
6
7
8
9
С
