12.2.5.1. Fire Condition Screen
The screen displays information about:
 the total number of zones in
Fire conition;
 the sequence number of the
indicated fire condition;
 the phase of Fire condition
detected by the fire control
panel in this particular zone;
 the zone number;
 the fire control panel that is in
Fire condition (Local or
remote control panel). After
the remote panel its address
is also displayed;
 the remaining time in
seconds before the fire
control panel proceeds to
phase Fire condition stage II
(indicated only in Fire condition stage I).
 text message for the respective zone
 the total number of activated outputs assigned to the zones in Fire condition;
 the activated output address and its loop;
Use the buttons and in the right part of the panel to display the next screen with
activated outputs if their total number is greater than 4.
12.2.5.2. From the Input Screen
The screen displays information about:
- the total number of
activated inputs;
- the activated input address
and loop;
- the fire control panel where
the activated input is;
- text message assigned to
the input;
- the total number of
activated outputs from the
input;
- the activated output
address and its loop;
Use the buttons and in
the right part of the panel to see the
next activated output, if there are
more;
Use the buttons and in the right part of the panel to display the next screen with
activated outputs if their total number for the output is greater than 4.
Press the button and enter password for Access Level 2 or 3 to reset the activated outputs
and inputs.
Mode DAY Loc ActInp 0000 11:11:08 Thu 11 Feb 2010
FIRE CONDITION
ZONES IN FIRE:
3
 1 Phase 2 Zone 001 LOCAL
Zone 001
3 Phase 1 Zone 002 REM #4
Zone 002
Time to phase2: 120
Activated outputs:
2
1 Loop 01 Addr 1.1
2 Loop 01 Addr 1.2
Total faults: 00000/0000*
Total disables: 000
Fault outputs:00000
Disabled outputs:000
Mode DAY Loc ActInp 0002 11:11:08 Thu 11 Feb 2010
Activated inputs
2
1 Loop 1 Addr.1.1 , Loc. panel
Emergency door
Activated outputs:
2
1 Loop 01 Addr 1.1
2 Loop 01 Addr 1.2
Total faults: 00000/0000*
Total disables: 000
Outputs in fault:00000
Disabled outputs:000
