UniPOS IFS7002 User Manual

UniPOS IFS7002 two signal loops
Instruction Manual Page 33
Revision 11/01.17 Of 145
12.2.4. Menu Input messages
The menu displays messages sent by activated addressable input devices.
Where no activated addressable
input devices are available, the
following screen appears:
Where activated addressable input
devices are available, the following
screen appears:
Each message is displayed in two
lines:
 Serial number of the
message, loop number, loop
address of the input device and
device’s input number, if more
than one input is available –
displayed on top line;
 Text message of the input –
displayed on bottom line.
Buttons and at the panel
right side allow for going to the next
or to the previous message, if any.
12.2.5. Menu Activated Outputs
This menu displays information about the activated inputs and outputs. It has two sub-menus –
for outputs activated in Fire condition and outputs activated from inputs.
Mode DAY LOC ActInp 0000 14:22:12 Mon 08 Mar 2010
FIRE CONTROL PANEL IFS7002
UniPOS
Inputs
Messages 0000
NO MESSAGES
Mode DAY LOC АctInp 0004 14:23:35 Mon 08 Mar 2010
FIRE CONTROL PANEL IFS7002
UniPOS
Inputs
Messages 0004
0001 Loop01 Addr005.1
Text Message
