UniPOS IFS7002 User Manual

UniPOS IFS7002 two signal loops
Instruction Manual Page 32
Revision 11/01.17 Of 145
12.2.3.2. Zone Status
If no disables of specific type are
available the following screen
appears:
If disables are available the status of
the first zone in Test Mode is
displayed:
Each message is displayed in
two lines, under the Status text
message:
 The first line displays zone
number and status;
 The line beneath displays text
message for the zone.
Buttons and in the right
panel section allow the user to
display the status of the next or the
previous zone (if any are available) in
Test Mode.
Press a button with figure and the field Go to situated on the heading of the panel is activated,and
you can enter a random 3-digit number of the zone. To correct the number use button ; the button
deletes the last digit you entered.
As soon as you enter a number in the field Go to, press button to display the status of the
specified zone:
 If you select zone number 0, the status of Zone 1 will be displayed;
 If you select zone number higher than 250, the status of Zone 250 will be displayed;
 If the selected zone is not set to Test Mode, a text message NOT IN TEST appears; the text
message for the zone is not displayed;
 The number in the Go to field is deleted, i.e. the field is deactivated.
С
Mode:DAY LOC ActInp 0000 10:12:28 Mon 08 Mar 2010
FIRE CONTROL PANEL IFS7002
UniPOS
List/Test/Zone Status
NO ZONES IN TEST
0
1
2
3
4
5
6
7
8
9
С
Mode:DAY LOC ActInp 0000 14:03:36 Mon 08 Mar 2010
FIRE CONTROL PANEL IFS7002
UniPOS
List/Test/Zone status Go to:
Zones in Test - Total 003
Status:
Zone 001 Normal status
Zone 001
0
1
2
3
4
5
6
7
8
9
С
