CLIMATE CONTROLLER C-46 - INSTALLATION AND OPERATION MANUAL
26
8.5.7 Supply information
The Supply information can be displayed if the Climate
Controller C-46 is set up in any Heating – outdoor controlled
mode.
The supply information is used as a tool when adjusting the heat
curve with the T-slope and T-adjustment parameters. The screen
displays the supply temperature for four different outdoor
temperatures.
For more information, see section 10.2
Adjusting the heat curve,
page 46.
To display the Supply information screen:
1. Navigate through the screens using the navigation keys:
Uponor > Main menu > Control settings > Heating >
Supply information
Example screen:
8.5.8 Indoor sensor influence
The indoor influence is a supply temperature adjustment that is
depending on the difference of the indoor temperature and the
indoor setpoint. This means that the supply will be increased if
the indoor temperature is to low and it will be decreased if the
indoor temperature is to high. The size of the adjustment is given
by the Indoor sensor influence parameter.
To set the Indoor sensor influence parameter:
1. Navigate through the screens using the navigation keys:
Uponor > Main menu > Control settings > Heating >
Indoor sensor influence
Example screen:
2. Select the desired settings.
Lower value:
• Default setting: 4
• Setting range: 0–8
• Setting accuracy: .11
Upper value:
• Default setting: 4
• Setting range: 0–8
• Setting accuracy: 0.1
3. Press OK to confirm the setting.
8.5.9 Indoor sensor mode
The screen Indoor sensor mode is available when one or more
indoor sensors are connected to the system through the
Controller C-56 Radio.
To set the indoor sensor mode parameters:
1. Navigate through the screens using the navigation keys:
Uponor > Main menu > Control settings > Heating >
Indoor sensor mode
Example screen:
2. Select Zone.
3. Select Mode and press OK.
• Default mode: Average
• Mode selections: Average, Maximum
8.5.10 Heating activation
When the Climate Controller C-46 is working in Heating or
Heating and cooling mode it is possible to set the Climate
Controller C-46 to be either Always active or to utilize a Summer
shut-off mode.
To set the heating activation mode:
1. Navigate through the screens using the navigation keys:
Uponor > Main menu > Control settings > Heating >
Heating activation
Example screen:
2. Select the desired mode.
3. Press OK to confirm the selection.
• If the mode Always active is selected, then the Climate
Controller C-46 returns to the Heating menu.
• If the mode Summer shut-off is selected, then the
menu Summer shut-off is displayed. See section below.
Summer shut-off
The summer shut-off function is used to save energy during the
period of the year when heating is not necessary. This will save
energy as the circulation pump will not be running.
Some use cases are given in section 10.3
Heating summer shut-
off and cooling winter shut-off, page 47.
To set the parameters needed for summer shut-off, do this:
1. Navigate through the screens:
Uponor > Main menu > Control settings > Heating >
Heating activation > Summer shut-off
Example screen:
