Urschel COMITROL 1700 - Page 199

(continued from page 125)
(The following items refer to the parts list on pages 124 & 125)
ITEM NO. PART NO. DESCRIPTION QTY.
24 * Circuit Breaker ....................................... 1
35 * Contactor ........................................... *
45 * Wiring Diagram, (see page 124 for location; also see pages 132–138) .... 1
PARTS
Electrical Assembly (CE compliant)
127
Enclos.
(see
page 34)
63828
63830
63829
63830
63831
63829
63830
Electrical
Ass'y
No.
63856
63833
63859
63834
63891
63862
63835
Motor
H.P.
15
15
30
30
30
40
40
Volts
400
400
400
400
230
400
400
Item 24
Circuit
Breaker
12848
*12847
12850
12849
*63567
*12869
*12850
Item 35
Contactor
& Qty.
12874 1
12874 3
12876 1
12874 3
12876 3
12876 1
12874 3
Item 45 Wiring
Diagram
Oil Mist Grease
Spindle Spindle
63858 63851
63832 63846
63861 63852
63838 63848
63892 **
63864 63853
63839 63850
Starting
Method
A-L
Y-D
A-L
Y-D
Y-D
A-L
Y-D
* Not included with enclosure.
** Contact Urschel Laboratories, Inc.
