Urschel COMITROL 1700 - Optional Parts

PARTS
Optional Parts
148
14
15
16
17
18
19
22
20
21
23
24
25
26
27
28
29
30
32
31
33
ITEM DIM. DIM.
NO. A B*
1 2.89" 7.63
2 4.00 6.80
3 8.00 4.73
4 12.00 2.80
ITEM DIM.
NO. B*
5 8.95
6 8.44
7 7.87
8 10.20
9 10.19
10 9.69
11 7.74
ITEM DIM.
NO. B*
12 8.95
13 8.44
* Mounting height from chamber includes 62639 sealing ring.
A
B
16.38"
B
B
