Ceilometer CT25K
CT25K-U059en-2.1 User’s Guide
3
- Shock Absorber CT35022 for ship installations
- PC Terminal cable CT35198 to connect the connector of the RS-232 port
of the PC to the maintenance port
1.2 Specifications
1.2.1 Mechanical
Dimensions:
Measurement unit 760 x 280 x 245 mm
(30 x 11 x 10 in.)
Height with shield and pedestal 1320 mm (52 in.)
Weight:
Measurement unit 17 kg (37 lb.)
Shield 10 kg (22 lb.)
Metal pedestal 8 kg (17 lb.)
Fiberglass pedestal (option) 13 kg (28 lb.)
Cardboard transport container size 1170 x 740 x 430 mm (46 x 29 x 17 in.)
Cardboard transport container weight 51 kg (111 lb.)
Plywood transport container size 1240 x 760 x 450 mm (49 x 30 x 18 in.)
Plywood transport container weight 70 kg (152 lb.)
1.2.2 External Connector J1 - Window conditioner
Connector J1: Type Binder series 693, 09-4228-00-07
(female)
Mating connector type: Type Binder series 693, 99-4225-70-07
7-pin (male) elbow
1.2.3 External Connector J2 - Power input
At nominal line voltage 115 V or 230 V
Power consumption (typical)
Total 365 W
Measurement unit 15 W
Internal heater 120 W
Window conditioner heater 200 W
Window blower 30 W
Frequency 45-65 Hz
