Ceilometer CT25K
CT25K-U059en-2.1 User’s Guide
43
LINES 3...6
Measured internal voltages in units of 0.1V, as follows:
BAT Battery voltage, e.g. 098
CHA Battery charge voltage, e.g. 144
VCA Internal raw voltage, e.g. 225
PHV Receiver high voltage, e.g. 2306
PFB Rec. switcher feedback voltage, e.g. 17
P65 Transmitter high voltage, e.g. 674
P18 General internal supply voltage, e.g. 178
P13 Receiver supply voltage, e.g. 128
P12 General internal supply voltage, e.g. 125
P5G General internal supply voltage, e.g. 54
P5R Receiver supply voltage, e.g. 50
M13 Receiver supply voltage, e.g. -124
M12 General internal supply voltage, e.g. -126
M5R Receiver supply voltage, e.g. -50
M5G General internal supply voltage, e.g. -54
LINES 8...13
Prevailing Receiver and Transmitter settings and variables as follows:
RECEIVER GAIN H or L Gain is High or Low
BAND N or W Bandwidth is Narrow or
Wide
SAMP 10MHz Sampling rate is 10 MHz
SENS OK Receiver sensitivity OK
compared to factory
setting
COMP 13 125 Internal crosstalk
compensation setting
codes, coarse (013) and
fine (125)
TRANSMITTER PLEN L or S Pulse length is Long or
Short
PQTY 64K Pulse quantity is 64x1024
OUT 1416mV Laser pulse energy
measured by Optics
Monitor is 1416 mV at
Monitoring A-to-D
Converter input.
SENS 101% Measured pulse energy is
101 % of nominal value
IN 190 Pulse energy control
input code is 190
