USER’S MANUAL__________________________________________________________________
268 _________________________________________________________________ M211322EN-D
0916-083
See Description for Input #11.
0916-084
0916-085
0916-086
Gas attenuation correction attempts to compensate for overall (two-way)
beam losses due to absorption by atmospheric gasses. The correction is
linear with range, and is added to the data along with range normalization.
Therefore, clearing the RNV bit in Word #2 above disables the correction.
Of course, gas attenuation compensation can still be turned off even when
RNV is on, simply by setting a slope of 0.0 dB/km.
An attenuation of G db/km is encoded into the unsigned 16-bit word N as
follows:
0 ≤ N ≤ 10000 G = N / 100000
else G = 0.1 + (N - 10000)/10000
This format is backward compatible with the previous linear format for all
values between 0.0 and 0.1 dB/km; but it extends the upper range of values
from 0.65535 up to 5.6535. These larger attenuation corrections are needed
for very short wavelength radars.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Threshold Control Flags for Width | Input 14
|_______________________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Additive Offset for Measured AZ Angles (Binary Angle) | Input 15
|_______________________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Additive Offset for Measured EL Angles (Binary Angle) | Input 16
|_______________________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Intervening Gas Attenuation Correction (dB/km) | Input 17
|_______________________________________________________________|
