USER’S MANUAL__________________________________________________________________
270 _________________________________________________________________ M211322EN-D
0916-092
Point clutter detection is configured with this word. A bin will be flagged
as containing clutter if it's power exceeds that of its two neighboring bins
by more than the detection threshold (in deciBels). Up to seven bins may
optionally be skipped on each side of the central bin prior to making these
two comparisons.
0916-093
Point clutter censoring is configured with this word.
0916-094
This word is a combination of MMTS_xxx bits specifying what types of
mismatches are okay (do not cause an all-zero ray to be produced) during
PROC command processing of timeseries data that are played back from
an external source into the RVP900.
Ena This bit is set to enable point clutter detection. Flag bits
will then be reported in the "Flg" output data type of the
PROC command.
Ena This is set to enable point clutter censoring. Raw moment
data containing point clutter will be interpolated from valid
signal levels on either side.
All Optionally expand the reported detection flags to show the
entire replaced interval, not just the original detected bins.
This gives a more honest view of the data bins that have
been altered.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
|Ena| | Point Clutter Thresh | Side Skip | XARG 3
|___|_______________________|_______________________|___________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
|Ena|All| | XARG 4
|___|___|_______________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Bit mask of TS playback mismatch conditions to ignore | XARG 5
|_______________________________________________________________|
