Chapter 7 __________________________________________________ Host Computer Commands
VAISALA______________________________________________________________________ 293
2 Number of Range Bins
3 Current trigger period
4 Current TAG00 - TAG15
5 Current TAG16 - TAG31
6 Log of Measured Noise Level
7 "I" Channel DC Offset
8 "Q" Channel DC Offset
9 Latched Processor Status
10 Immediate Status Word #1
11 Diagnostic Register A
12 Diagnostic Register B
13 Number of Pulses/Ray
14 Trigger Count (Low 16-bits)
15 Trigger Count (High 8-bits)
16 No. of Properly Acquired Bins
17 No. of Properly Processed Bins
18 Immediate Status Word #2
19 Noise Range in Km
20 Noise Trigger Period
21 Pulse Width 0 min. Trig. Period
22 Pulse Width 1 min. Trig. Period
23 Pulse Width 2 min. Trig. Period
24 Pulse Width 3 min. Trig. Period
25 Pulse Width Bit Patterns
26 Current/Pulse Width
27 Current Trigger Gen. Period
28 Desired Trigger Gen. Period
29 PRT at Start of Last Ray
30 PRT at End of Last Ray
31 Processing/Threshold Flags
32 Log Slope
33 LOG Threshold
34 CCOR Threshold
35 SQI threshold
36 SIG Threshold for Width
37 Calibration Reflectivity
38 Reserved
39 Reserved
40 Range Averaging Choice
41 Reserved
42 Reserved
43 Header configuration of PROC data
44 I-Squared Noise (Low 16-bits)
45 I-Squared Noise (High 16-bits)
Table 14 RVP900 Status Output Words (Continued)
Word Description
