USER’S MANUAL__________________________________________________________________
294 _________________________________________________________________ M211322EN-D
0916-118
The revision and serial numbers of the particular RVP900 board are
accessible here. This information is useful when computer software is
being designed to handle a variety of signal processor revisions. The
revision number is seven bits total; four of which are still in the high four
bits of the word for compatibility with an older format.
46 Q-Squared Noise (Low 16-bits)
47 Q-Squared Noise (High 16-bits)
48 Log of Measured Noise Level
49 LOG Noise Standard Deviation
50 Horizontal/Vertical Noise Ratio
51 AFC/MFC Control Value
52 Interference Filter Select
53 Interference Filter C1 Constant
54 Interference Filter C2 Constant
55 Immediate Status Word #3
56 Burst Tracking Slew
57 Polarization Algorithm Choices
58 Range Mask Spacing
59 Immediate Status Word #4
60 Reserved
61 Reserved
62 Reserved
63 Reserved
64 Reserved
Table 14 RVP900 Status Output Words (Continued)
Word Description
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| | 0 1 0 0 1 | Command
|___________________________________________|___________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Rev Bits 3–0 | Rev 6–4 | Serial Number | Output 1
|_______________|___________|___________________________________|
