USER’S MANUAL__________________________________________________________________
304 _________________________________________________________________ M211322EN-D
0916-137
0916-138
This is the same format that is used by the SETSLEW command to set the
current trigger slew (see Section 7.25 Set Trigger Timing Slew
(SETSLEW) on page 326).
0916-139
Bit 0 Burst pulse timing adjustments can be made
Bit 1 Burst pulse frequency adjustments can be made
Bit 2 Burst pulse hunting is enabled
Bit 3 Burst pulse hunt is running right now
Bit 4 Last burst pulse hunt was unsuccessful
Bit 5 Processor supports DPRT-2 (Dual-PRT) algorithms
Bit 6 Could not generate the requested phase sequence
Bit 7 Unused
Bits 8-11 User-defined Major Modes 1 through 4 are supported
Bit 0 Use H transmissions for (T,Z,V,W)
Bit 1 Use V transmissions for (T,Z,V,W)
Bit 2 Use Co-Pol reception for (T,Z,V,W)
Bit 3 Use Cross-Pol reception for (T,Z,V,W)
Bit 4 Correct all polar Parameters for noise
Bit 5 Use filtered data for all polar Parameters
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Interference Filter Parameter “C1” in Hundredths of deciBels | Output 53
|_______________________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Interference Filter Parameter “C2” in Hundredths of deciBels | Output 54
|_______________________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Immediate Status Word #3 (Current State of Affairs) | Output 55
|_______________________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Signed trigger slew in hundredths of microseconds | Output 56
|_______________________________________________________________|
