Chapter 7 __________________________________________________ Host Computer Commands
VAISALA______________________________________________________________________ 305
0916-140
0916-141
Bit 6 Sign convention for PhiDP
Bit 7 Z and Z
dr
are corrected for attenuation using PhiDP
Bit 0 Internal power spectra size matches sample size (else
power-of-2)
Bit 1 PROC command output spectra match sample size (else
power-of-2)
Bit 2 Trigger pattern has been altered to fit within the desired
PRT
Bit 3 PRT has been altered to preserve the desired trigger pattern
Bit 4 Using High-SNR packed (I,Q) format
Bit 5 Trigger sequence truncated due to insufficient pattern
memory
Bit 6 Time series data source is external to the RVP900
Bit 7 WSR88D "Batch" mode is supported
Bit 8 Major mode refuses to use external trigger
Bit 9 GPARM outputs #7 and #8 use Hi-SNR format, else linear
Bit 10 Receiver protection fault
Bit 11 IFDR dual-channel inconsistency (for example, power
and/or phase out of bounds for ratio of HiGain-to-LoGain
channels)
Bit 12 GPS 1-pulse-per-second input clock error
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Range mask spacing for current pulsewidth (centimeters) | Output 58
|_______________________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Immediate Status Word #4 (Current State of Affairs) | Output 59
|_______________________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Reserved (Zero) | Output 60
|_______________________________________________________________|
.
.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Reserved (Zero) | Output 64
|_______________________________________________________________|
