Vaisala RVP900

USER’S MANUAL__________________________________________________________________
344 _________________________________________________________________ M211322EN-D
5 Diagnostic Results 14–20
D6 = GP12,D4 = <spare>
D5 = GP12,D3 = <spare>
D4 = GP12,D2 = <spare>
D3 = GP12,D1 = <spare>
D2 = GP12,D0 = <spare>
D1 = GP11,D15 = <spare>
D0 = GP11,D14 = <spare>
6 Diagnostic Results 21–27
D6 = GP12,D11 = <spare>
D5 = GP12,D10 = <spare>
D4 = GP12,D9 = <spare>
D3 = GP12,D8 = <spare>
D2 = GP12,D7 = <spare>
D1 = GP12,D6 = <spare>
D0 = GP12,D5 = <spare>
7 Shutdown Conditions 28–34
D6 = <spare>
D5 = <spare>
D4 = <spare>
D3 = GP12,D15 = <spare>
D2 = GP12,D14 = <spare>
D1 = GP12,D13 = <spare>
D0 = GP12,D12 = <spare>
8 Immediate Status 0–7
D6 = GP10,D6 = Angle sync not interruptible
D5 = GP10,D5 = Angle sync enabled
D4 = GP10,D4 = Angle sync on elevation
D3 = GP10,D3 = Angle sync is BCD
D2 = GP10,D2 = PWINFO command is disabled
D1 = GP10,D1 = Error loading trigger angle table
D0 = GP10,D0 = No trigger
9 Immediate Status 8–14
D6 = GP10,D13 = # compute processes –1 (bit 1)
D5 = GP10,D12 = # compute processes –1 (bit 0)
D4 = GP10,D11 = Current unfolding mode (bit 1)
D3 = GP10,D10 = Current unfolding mode (bit 0)
D2 = GP10,D9 = DSP supports 16-bit floating time series
D1 = GP10,D8 = DSP has full IAGC hardware support
D0 = GP10,D7 = Angle sync is dynamic
10 Immediate Status 15–21
D6 = GP18,
D4 = IFD uplink cable failure
D5 = GP18,D3 = DSP supports DPRT–1 algorithms
D4 = GP18,D2 = <spare>
D3 = GP18,D1 = DSP supports random phase algorithms
D2 = GP18,D0 = DSP supports FFT algorithms
D1 = GP10,D15 = <spare>
D0 = GP10,D14 = DSP supports power spectrum output
Table 15 Internal BITE Packet (RVP900 to Host) (Continued)
Char Function
