Vaisala RVP900

Appendix A ______________________________________________________ Serial Status Formats
VAISALA______________________________________________________________________ 345
11 Immediate Status 22–28
D6 = GP18,D11 = IFDR test switches are not in normal position
D5 = GP18,D10 = AFC status (bit 2)
D4 = GP18,D9 = AFC status (bit 1)
D3 = GP18,D8 = AFC status (bit 0)
D2 = GP18,D7 = IFDR PLL is not locked to external reference
D1 = GP18,D6 = <spare>
D0 = GP18,D5 = IFDR downlink cable failure
12 Immediate Status 29–35
D6 = GP55,D2 = Burst pulse hunting is enabled
D5 = GP55,D1 = Burst pulse frequency changes can be made
D4 = GP55,D0 = Burst pulse timing changes can be made
D3 = GP18,D15 = Burst at incorrect range
D2 = GP18,D14 = <spare)
D1 = GP18,D13 = Missing signal at IFD #1 burst
D0 = GP18,D12 = Trigger blanking is enabled
13 Immediate Status 36–42
D6 = GP55,D9 = User-defined Major mode #2 supported
D5 = GP55,D8 = User-defined Major mode #1 supported
D4 = GP55,D7 = Problem with digital transmitter clock
D3 = GP55,D6 = Count not generate the requested phases
D2 = GP55,D5 = DSP supports DPRT-2 algorithms
D1 = GP55,D4 = Last burst pulse hunt was unsuccessful
D0 = GP55,D3 = Burst pulse hunt is running now
14 Immediate Status 43–49
D6 = GP59,D0 = Power spectra size matches sample size
D5 = GP55,D15 = <spare>
D4 = GP55,D14 = <spare>
D3 = GP55,D13 = <spare>
D2 = GP55,D12 = <spare>
D1 = GP55,D11 = User-defined Major mode #4 supported
D0 = GP55,D10 = User-defined Major mode #3 supported
15 Immediate Status 50–56D6 = GP59,
D7 = WSR88D Batch mode is supportedD5 = GP59,
D6 = Time series data source is external to RVP900D4 =
GP59,
D5 = Trigger sequence truncatedD3 = GP59,
D4 = Using High-SNR packed (I,Q) formatD2 = GP59,
D3 = PRT altered to fit trigger patternD1 = GP59,
D2 = Trigger pattern altered to fit PRTD0 = GP59,
D1 = PROC spectra size matches sample size
16 Immediate Status 57–63
D6 = GP59,D14 = <spare>
D5 = GP59,D13 = <spare>
D4 = GP59,D12 = <spare>
D3 = GP59,D11 = <spare>
D2 = GP59,D10 = Receiver protection fault
D1 = GP59,D9 = GP outputs #7&8 use Hi-SNR format
D0 = GP59,D8 = Major mode refused to use external trigger
Table 15 Internal BITE Packet (RVP900 to Host) (Continued)
Char Function
