Table 16 Internal QBITE Packet (RVP900 to Host)
Char Function
1 SYNC Byte (AF Hex)
2 Identification byte (User Choice)
3–4 Burst pulse frequency, IFDR #1
5–6 Burst pulse frequency, IFDR #2
7–8 Burst pulse power, IFDR #1
9–10 Burst pulse power, IFDR #2
11–12 Noise level, IFDR #1
13–14 Noise level, IFDR #2
15–16 Chassis temperature, IFDR #1
17–18 Chassis temperature, IFDR #2
19–20 FPGA temperature, IFDR #1
21–22 FPGA temperature, IFDR #2
23–24 AFC setting
25–26 Burst timing slew
27–28 Current PRF
29–30 Current pulse width
31–62 <spare>
63 END OF MESSAGE (FF Hex)
