Table 23 J6 “STC #2”
Pin Type Dir Signal Name Comment
6/19 RS-422 Out STCDATA/STCDATAn STC Serial Loadup Data
7/20 RS-422 In TRLFLT/TRLFLTn TRL Fault
8/21 RS-422 In STCFLT/STCFLTn STC Fault
25 — — GND Common Ground
Table 24 J7 “Stability Monitor”
Pin Type Dir Signal Name Comment
7/20 RS-422 In STABFLT1/STABFLT1n Stability Monitor Fault #1
8/21 RS-422 In STABFLT2/STABFLT2n Stability Monitor Fault #2
9/22 RS-422 In STABBSY/STABBSYn Stability Monitor Busy
10/23 RS-422 Out XMTSTABEN/XMTSTABENn Enable Stability Monitor
25 — — GND Common Ground
Table 25 J8 “REX Power”
Pin Type Dir Signal Name Comment
8/10 Analog In REX5VA/REX5VAn REX +5V Power Monitor #1
21/23 Analog In REX5VB/REX5VBn REX +5V Power Monitor #2
9/11 Analog In REX18VA/REX18VAn REX +18V Power Monitor #1
22/24 Analog In REX18VB/REX18VBn REX +18V Power Monitor #2
25 — — GND Common Ground
