PHASEBIT_P/N3 RVP Latched in on rising edge of
trigger 10
PHASEBIT_P/N2 RVP Latched in on rising edge of
trigger 10
PHASEBIT_P/N1 RVP Latched in on rising edge of
trigger 10
CHANFAIL_P/N RCP sAux[61]
OPFREQREFFL_P/N RCP sAux[60]
COHOREFFAIL_P/N RCP sAux[58]
PHMODFAIL_P/N RCP sAux[63]
PHCOHOSEL_P/N RCP/RVP cAux[49],
trigger 11
cntPhaseForce = "true", "false"
RFGATE_P/N RVP trigger 1
J8
DRSIGPOS_P/N4 RCP cAux[42]
DRSIGPOS_P/N3 RCP cAux[43]
DRSIGPOS_P/N2 RCP cAux[44]
DRSIGPOS_P/N1 RCP cAux[45]
J9
DRIVESIG40DB_P/N RCP cAux[31]
DRIVESIG32DB_P/N RCP cAux[32]
DRIVESIG16DB_P/N RCP cAux[33]
DRIVESIG8DB_P/N RCP cAux[34]
DRIVESIG4DB_P/N RCP cAux[35]
DRIVESIG2DB_P/N RCP cAux[36]
DRIVESIG1DB_P/N RCP cAux[37]
J10
NOISECTRLIN_P/N RCP cAux[47]
P5ION_P/N RCP cAux[46]
J11
DRSIGBIT_P4 RCP cAux[38]
DRSIGBIT_P3 RCP cAux[39]
DRSIGBIT_P2 RCP cAux[40]
DRSIGBIT_P1 RCP cAux[41]
J20
RVP9_TP1 RVP dspx debug options
J21
Table 33 Software Control/Status Variable
Signal Name Controlling
Process
Programmable
Logic Variable
Conditions
