4. Start the 4 air guide fasteners by hand (A, Figure 171).
Tighten to 195 lb-in (22 Nm).
171
NOTE: Your engine may be equipped with an air filter
support bracket ora speed control bracket. These brackets
utilize the valley air guide fasteners to attach to the
engine.See Figure 172 for engines equipped with the low-
profile air cleaner support bracket, and see Figure 173 for
engines equipped with the speed control bracket.
172
173
5. If equipped, install the valley component bracket (A,
Figure 174) in the valley of the engine block.
174
6. Start the 2 component bracket fasteners by hand.
Tighten to 90 lb-in (10.2 Nm).
133
