6.1.2. CEPH Sensor Setting
To set CEPH sensor, use the following commands:
Command Function
[SPM_CEPH] CEPH mode
[SPM_HSON] CEPH sensor power on
[SPM_FREQ_0160] Norm Mode Sensor Frequency Setting
[SPM_FREQ_0313] Fast Mode Sensor Frequency Setting
[SPM_COLM_0003]
Collimator Open Position (without cu filter)
If the collimator is not completely opened,
adjust with [SPM_CDST_XXXX]
[SPM_COLM_0004]
1T Cu + AL filter position (with cu filter)
If 1T Cu + Al Filter is not completely covered,
adjust with [SPM_CEST_XXXX]
[SPM_COLM_0005]
CEPH Mode Collimator location
[CEPH Sensor Setting Command List]
Please follow the note below before setting the CEPH sensor:
Before the Ceph Sensor Calibration operation begins, the operator must
back up the prior Ceph Sensor Calibration folder.
Fast: C:\VCaptureSW\Acquisition\Ceph\WideCephG\Fast\CAL
Norm: C:\VCaptureSW\Acquisition\Ceph\WideCephG\Norm\CAL
