Page 60 of 244
2.3.3. CT Sensor Setting
To set the CT sensor, use the following commands:
Command
Function
[SPM_ARCT] CT mode
[SPM_CSON] CT sensor power on
[SPM_FISS_0001] Normal Mode : 4x4 binning & High gain
[SPM_FIPM_0001] Sensor size setting
[SPM_FISM_0001] Sensor clock (1:External, 0: Internal)
[SPM_FREQ_0100] Sensor frequency 100 Hz
[SPM_COLM_0003]
Collimator Open Position
If the collimator is not completely open after entering this command,
adjust with adjust with [SPM_CDST_XXXX]
[SPM_COLM_0004]
1T Cu + AL filter Position (4-Point)
If 1T Cu + Al Filter is not all covered, send [SPM_CBST_XXXX] to adjust.
[SPM_AAMS] U offset driven
[SPM_ABMS] FOV 8x8 driven
[CT Sensor Command List]
For CT sensor calibration, you must have a VAKCAP.exe file (Path:
C:\VCaptureSW\Acquisition\CBCT\WidePANO\CAL).
