2.5.4.2 Pin Alignment
If the pins are not aligned, follow the instructions below
1. Unscrew the two bolts (1)
2. When rotating the chinrest module counterclockwise, the top pin moves to the right
3. When rotating the chinrest module clockwise, the top pin moves to the left.
4. Repeat the process 1) to 3) until all three pins are aligned in a stright line.
Example
Turn Clockwise
When rotating the module
counterclockwise, the top pin
moves to the right
When rotating the chinrest
module clockwise, the top
pin moves to the left.
