4 PRODUCTDESCRIPTION
ThischaptercontainsrelevantinformationaboutthecontrolunitMDC3200AandthevalveMDC
3200A.Itdescribesthemenustructure,keypadandfunctionsofthecontrolunit,aswellasthe
structureandthehardwareconfigurationofthevalve.
4.1 ControlUnitMDC3200A
4.1.1 TechnicalData
 
Dimensions 128mmHx102mmWx173mmD(w/ocable)
128mmHx102mmWx185mmD(withcable)
3HEx20TE
Weight ca.1500g
SupplyVoltage 110/230VAC/DC
SupplyFrequency 50/60Hz
CurrentCons umption 900mAmax.
Duringstart‐up,thisvaluemaybeincreasedbya
factorof5(start‐uppeak).
Recommendedfuse:16Afor240Vresp.110V
OperatingTemperatu re 0°Cto50°C
AirHumidity 35%till95%rH
CasingType Plug‐incasefor19“rack
ColorofCasing Black,withlighterfrontplate
Ventilation Convection
Internalstoragelocations: 10(seepage21)
Displaylines 2lineswith16characterseach
Displayillumination  Whitewithbackgroundlighting
Keypad 12softkeys
Colorofkeys  Blue
Controllamps(Frontside)  1xHeatingcircuit(red)
1xServicerequest(red)
1xAdjustOK(green)
1xAdjustnotOK(red)
Controllamps(Backside) 1xIlluminatedpowerlamp
Plugcontacts(Backside) 1xMainsplug(110/240VAC)
1x9pinSub‐DRS‐232C
1x15pinSub‐DPLC
1xAux‐output24V
1xSensorsocket
1xActuatorsocket
1xSocketforheating
1xThermocouplesocket







