VTK‐VS‐BA‐004e‐B|UserManualMDS3200A | General Instructions
8
2.3 Tools
ThefollowingtoolsarerequiredtoinstallandtooperatetheMDS3200A:
 MDT301Universaltool
(Partno.1010208)
 MDT302Nozzleadjustingtool
(Partno.1009289)
 MDT303Nozzleinsertchangingtool
(Partno.1007083)
 MDT304Toolforsqueezingoutnozzleinserts
(Partno.1007085)
 MDT310Tappetchangingtool
(Partno.1008344)
 MDT312ToolfortappetsealingFX
(Partno.1012825)
 Hexagonsocketkeyset
(Partno.1012993)
Whenyouordertools,alwaysspecifythepartnumberoftherequireditem.

IMPORTANTNOTE!(Noforeigntools)
Donotuseauxiliarytoolsorforeignproducts,otherwisedamagestotheequipment
mightbepossible.
2.3.1 MDT301UniversalTool
ThetoolMDT301consistsoftwosubcomponentsscrewedtoeachother:
 “Sealmounter“withamandreltoinsertandtoremovethetappetseal
(1.)
 “Adjustmentgrip“withareceptacleforthenozzleadjustingnut(2.)
IntendedPurpose:
1. Fixingandremovingoftappetsealingandtappetcenteringpiece
2. Itmayalsobeusedtoexecutethegeneraladjust
(alternativelytotoolMDT302describedbelow)
2.3.2 MDT302NozzleAdjustingTool
Thisparthasareceptacleforthenozzleadjustingnutandalongerleverto
simplifythegeneraladjust.ItcanalsobeusedincombinationwithMDT310,if
abetterleverageisneeded.
IntendedPurpose:
1. Performingtheadjust
2. Fixingthetightingscrewtothefluidbox
3.
ChangingoftappetincombinationwithMDT310
2.3.3 MDT303NozzleInsertChangingTool
TheMDT303isrequiredfortheexchangeofthenozzleinsert.The3pinsof
theMDT303gripintothereceptacleboresofthetappetguidanceinorder
tounscrewthetappetguidancefromthenozzleadjustmentnut.
IntendedPurpose:
1. Screwingapartnozzleadjustingnutandtappetguidance
whenchanging
thenozzleinsert
2.3.4 MDT304NozzleInsert–SqueezingOutTool
ThediametersoftheendpiecesoftoolMDT304arenotidentical,aseachof
themisusedforadifferentpurpose:
IntendedPurpose:
1. Squeezingoutofthetappetsealingbetweenfluidboxandactuator
(1.)
2. Detachingthenozzleinsertfromthetappetguidance
(2.)
 
