VTK‐VS‐BA‐004e‐B|UserManualMDS3200A | General Instructions
9
2.3.5 MDT310TappetChangingTool
TheMDT310featuresaborewithtwostuds,servingasareceptacleforthe
tappet.Whenexchangingthetappet,carefullypushitintothisboreuntilthe
studslatchintothegroovesofthetappetcenteringscrew.Thenthecentering
screwcanbeinsertedorremovedbyrotatingthetool
(whileapplyingalight
constantpressure).
IntendedPurpose:
1. Removingthepresenttappetandfixinganewone
2.3.6 MDT312TappetSealingToolFX
TheMDT312consistsofatoolbodyandanejectorpin.Itismeantfor
mountinganddismountingthetappetsealingFX,especiallyformounting
ordismountingthetappetsealingbushingFX.
IntendedPurpose:
1. MountingthebushingofthetappetsealingFX
2. Disengagingofthetoolitself(attheendoftheprocedure)
2.3.7 HexagonSocketKeySet
Thesetincludesthreekeys(sizes2,2.5and3)forhex‐screws,withblades
madeofhardenedsteelandergonomicgrips.
IntendedPurpose:
1. Mountinganddismountingthefluidbox(2)
2. Mountinganddismountingthetappetguard(2)
3. Mountinganddismountingthecartridgeholder(2.5)
4. Installationof
heatertypeMDH‐230te(2.5)
5. Fixingofthevalve,in‐situ(3)

2.3.8 Torques
Element Torquemin.(Nm) Torquemax.(Nm)
Screwsforfluidbox(M2,0x8) 0,8 1
TightingscrewforMDF3070‐CC 1,2 1,4
FluidboxconnectorLuer‐Lock 1,0 1,2
TappetguidancePEEK 0,4 0,6
TappetguidanceH 0,8 1
Tappetcenteringscrew 1,0 1,4
TStappet 0,22 0,22

