VTK‐VS‐BA‐004e‐B|UserManualMDS3200A | Communication Interfaces
38
7 COMMUNICATIONINTERFACES
7.1 SerialInterfaceRS‐232C:9‐PinSub‐D





ThislocalinterfaceisstructuredaccordingtoSCPIStandard.These“StandardCommandsfor
ProgrammableInstruments“representastandardizedsetofinstructionsusedforcontroland
programming,transmittedinformofASCIItext.Theycanbegeneratedbyanyselectablepro‐
gramminglanguageinanyenvironment.Theserialinterfaceis
operatedbymeansofsoftware
handshake.Thehardwarehandshakecommunicationsarenotinuse.

INFORMATION!(Communicationwhiletriggering)
Theusershouldbearinmindnottosendinstructionsthroughthisinterfaceinthecourseofarun‐
ningdispensingcycle.Communicationisonlypossiblebetweendistinctsequences.
Aftersendingdata
orparameterstothecontrolunityouhavetowaitforthe“OK”signalbefore
youcanstartfurtheractions.
7.1.1 FunctionsAllocatedtothedifferent Pins
PIN Characteristics Level Function
1 Reservedforfutureuse
___________ ___________
2 Input TX Serialtransmissionsignal
3 Input RX Serialreceptionsignal
4   ConnectedtoPIN6
5 Ground  Ground
6   ConnectedtoPIN4
7
___________

___________

___________

8
___________

___________

___________

9
___________

___________

___________


TheMDC3200ARS‐232ClogusesRS‐232CStandardandisdesignedforcommunicationby
meansofaserialcable,connected1:1,withaSub‐D9pinconnector.

ThefollowingparameterconfigurationisusedforMDC3200Acommunication:
 Synchronousmode:Half‐duplex
 Bits/s:9600

Startbit:1
 Stringlength:8bit(ASCII)
 Parity:None
 Stopbit:1
 Log:None


