VTK‐VS‐BA‐004e‐B|UserManualMDS3200A | Product Description
23
4.5.2 ExplosionViewMDV3200A withMDX3080‐ CC‐10


4.5.3 Specification
Parameter Value
DispensableQuantity <2nlupto>200µlpercycle(forhighlyviscousme‐
dium)
InletPressureRange

0,1to70bar(rel.)
0,1to8barwithcartridge
0,1to70barwithpressuretank
DynamicViscosityofFluids Mediumandhighviscosityupto2.000.000mPas
ResponseTime(PLC‐interface) ca.104µs
DispensingFrequency(max.) 2kHz
DispensingFrequency(average) 580Hz(cooled)
OperatingTemperature from10°Cto50°C
Compatibility Allaqueousfluids,organicsolvents,weakacidsand
bases
Dimensions(basicmodel) 115mmx39,5mmx12mm
Weight ca.258g(dependingonconfiguration)
PositionofTappetinAbsenceofVoltage open



