5 INITIALOPERATION
5.1 Delivery
VERMESsystemsareshippedincarefullypackedstate.Transportdamageshowevercan
neverbetotallyexcluded,anddeadlinesstatedininsurancecontractsshouldnotbeex‐
ceeded.

5.1.1 Unpacking
Forthisreason,themerchandisehastobevisuallyinspectedimmediatelyafterreceipt.
Detecteddamagesmustbenotifiedtothecarrier.Assoonasthecomplainthasbeencon‐
firmedinwriting,contacttheresponsibleforwarderandinformVERMESMicrodispensing.
Otherwiseunpackthecontainedsubcomponentsandcheckthedeliveryforcompleteness.

5.1.2 Content
Accordingtothepurchaseorder,thefollowingcomponentsmaybeincluded;
someofthemarealreadypreassembled:

Basicequipment:
1.ControlunitMDC3200A  8.MDT302NozzleAdjustingTool
2.MicroDispensingValveMDV3200A9.CDwithusermanualandsoftware
3.Fluidbox*10.MDT304NozzleInsert–SqueezingOutTool
4.Nozzleunit*11.Actuatorcable(red)*
5.Nozzleinsert* 12.Sensorcable(yellow)*   
6.MDT303NozzleInsertChangingTool 13.Mainscable(black)
7.Tappetguard

*Thesepartsareincludedonly,iforderedexplicitly.















Options:Recommendedoptions:
‐Differentmodelsoffluidboxes ‐Cleaningset
‐Differentfluidboxconnectors ‐MDT301UniversalTool
‐Nozzleheating

Iftheintendedapplicationneedsparticularaccessories(e.g.sealsmadeofspecialmaterial),
consultourTechnicalSupportatonce.Donotstartthesysteminincompletestate.
