6.4 MinimumandMaximumValuesofParameters
Parameter Min.Value Max.Value ConversionValue
Rising(RI) NL1%=RI0.01ms
NL10%=RI0.03ms

NL20%=RI0.06ms
NL30%=RI0.09ms
NL40%=RI0.12ms
NL50%=RI0.15ms
NL60%=RI0.18ms
NL70%=RI0.21ms
NL80%=RI0.24ms
NL90%=RI0.27ms
NL100
%=RI0.30ms
300ms

*10

e.g.
RI=0,5ms≙5
Falling(FA) NL1%=RI0.01ms
NL10%=RI0.01ms
NL20%=RI0.02ms
NL30%=RI0.03ms
NL40%=RI0.04ms
NL50%=RI0.05ms
NL60%=RI0.06ms
NL70%=RI0.07ms
NL80%=RI0.08ms
NL90%=RI0.09ms
NL100%=RI0.10ms
300ms *10

e.g.
FA=0,8ms≙8
OpenTime(OT) 0ms NL0‐80%=3000ms
NL81‐100%=15ms
*10

e.g.
OT=2ms≙20
NeedleLift(NL) 1% 100% *1

e.g.
NL=50%≙50
NumberofPulses 1Puls 32000pulses *1

e.g.
NP=80≙80
Delay(DL) 0ms
(4,6mswithheater)
1000ms *10

e.g.
DL=5ms≙50
Heater Ambienttemperature 120°C 120
