VTK‐VS‐BA‐004e‐B|UserManualMDS3200A | Initial Operation
28
CAUTION!(Readchapter“Safety”first)
Theentireprocedureofinstallationisreservedtopersonsreliablyinformedaboutthe
safetyconsiderationsdiscussedinchapter3.
5.3.1 Installationofthe MDC3200A
Thecontrolunitisdesignedasa19“plug‐inmodule,whichhastobefixedinthecorre‐
spondingrackbymeansoffourpan‐headscrewsatthefrontside.Leavesufficientspace
aroundtheunittosimplifyservice.Ventilationshouldbeavailable.Werecommendcases
complyingwithenclosures
accordingtoEN61010‐Ewithregardtofireprotection.
ImportantNote!(PossibledamagetotheMDC)
Don’tturnthefourpan‐headscrewsmentionedabovetootight;otherwisethefrontplate
canbedamaged.
Toavoidoverheatingandensuretherequiredaeration,aminimumdistancebetweenthe
controlunit
andanyotherobjectshouldbemaintained(atleast1,5cm).Heatshouldneither
beaccumulatednorexternallybeintroduced.Donotobstructnaturalconvection.Ventilation
fromthebottomsideandairexhaustfromaboveisimportant.Minimumwidthofventilation
openingsis8cmx8cm.
For
high‐dutyapplications(fromca.300Hz)orinthecaseofanair‐cooledmodel(ACvari‐
ants),arackwithseparateventilationisadvisable,sinceinthesesituationsanairflowof
100m
3
/hforeachMDC3200Aiscompulsory.


