• Name - The target name assigned to the UMIQ module. Clicking this name will enable you to modify individual
module settings.
NOTE: To rename a target, see Targets on page 36.
• IPAddress - The IPaddress assigned to the module via the appliance DHCPserver.
NOTE: UMIQmodules will be discovered by the appliance only after they are issued an IPaddress from the appliance
DHCPserver. This means UMIQmodules cannot be used if the DHCP server is disabled or if the port connecting the
UMIQmodule to the appliance belongs to a bridge group.
• EID - Displays the unique electronic ID number embedded in the module.
• Status - Displays whether the module is In-Use, Idle or Offline.
• Management - Displays whether the module is Pre-discovered, Managed or Not Managed. During the initial
connection or during a factory reset, as the module is being discovered the management status will change
from Pre-discovered to Managed.
• Appliance Power - Displays if the appliance is providing power to the module.
• Power Mode - Displays the power status for the module. Full means the module is getting power from the
appliance and the target. Partial means that the only power is from the appliance.
Module settings
To display a module's individual settings:
Click a module name. For a detailed explanation of the settings, see Default settings on page 56.
To enable or disable the Flash Locator LED:
Enable the checkbox and verify the LED on the module is flashing to help you locate it.
Upgrading UMIQ modules
The UMIQ moduleFlash upgrade feature allows appliance administrators to update UMIQ modules with the latest firmware
available.
After the Flash memory is reprogrammed with the upgrade, the appliance performs a soft reset, which terminates all UMIQ
module sessions. A target device experiencing an UMIQ modulefirmware update may not display, or may display as
disconnected. The target device will appear normally when the Flash update is completed.
UMIQ modules are automatically updated when the appliance is updated. To update your appliance firmware, see Firmware
on page 60.
If issues occur during the normal upgrade process, UMIQ modules may also be force upgraded when needed.
NOTE: Check www.VertivCo.com for firmware upgrade files.
To upgrade the UMIQ module firmware:
1. From the sidebar, click Targets - KVM Management to open the UMIQ module screen.
2. Select the checkbox next to the UMIQ moduleyou wish to upgrade, and click Upgrade.
CAUTION: Disconnecting an UMIQ moduleduring a firmware update or cycling power to the target device
will render the module inoperable and require the IQ module to be returned to the factory for repair.
Factory reset
After the module has been configured, you can return it to the factory default settings.
To factory reset UMIQ modules:
1. From the sidebar, click Targets - KVM Management to open the Appliance UMIQ screen.
2. Select the checkbox next to the UMIQ module you wish to delete, and click Factory Reset.
