Figure 2.9 GXT5-3000IRT2UXLA Rear Panel
Item Description
1 Vertiv™ Liebert® IntelliSlot™ port
2 Ventilation Hole
3 EBC connector
4 Input circuit breaker
5 Non-programmable output receptacles
6 Programmable output receptacles
7 Input-power plug and cable
8 Dry contacts, Battery Detection (3), REPO input (REPO)
9 RS-232 port – Used for CLI
10 RS-485 port – Used for external temperature sensors
11 USB port
12 Output circuit breakers
13 Output-power plug and cable
12 Proprietary and Confidential ©2024 Vertiv Group Corp. 2 Product Description
Vertiv™ Liebert® GXT5 UPS Installer/User Guide
