Figure 13.7 Termination Jumper on 2T Circuit Board
Item Description
1 Position 1 (P3 jumper)
2 Position 2 (P3 jumper)
3 Position 3 (P3 jumper)
4 Unterminated
5 Terminated
6 Rear of sensor, cover removed
7 P3 termination jumper
