Line
ID
Parameter
Name
Range
Default
Setting
Description
S216
High Dew Point
34 - 210 °F
1.0 - 99.0 °C
59 °F
Sets the high/low dew point threshold.
Low Dew Point
34 - 210 °F
1.0 - 99.0 °C 39 °F
S217
Sensor A Dew Point
Alarms Enable
Disabled Enabled Disabled
Enables or disables the optional Sensor A Dew Point alarm. Dew
Point alarms can be enabled with any humidity control type. Dew
point alarms may be used with or without humidification or
dehumidification options selected. A user may adjust the time
delay before the alarm is activated.
Sensor A Dew Point
Alarms Init Delay
10 - 9999 sec 90 sec
S218
High Dew Point
Sensor A
34 - 210 °F
1.0 - 99.0 °C
62 °F
Sets the high/low Sensor A dew point thresholds.
Low Dew Point
Sensor A
34 - 210 °F
1.0 - 99.0 °C
36 °F
S219
Remote Sensor
Alarms Enable
0 = Disabled
1 = Com Set
2 = Sep Set
Disabled
Disable prevents remote temperature sensor alarms from
occurring. Com Set or common setting allows remote alarm
activation based on a common alarm setting. Sep Set, or separate
setting allows the user to program unique temperature alarm
settings. A user may adjust the time delay before the alarm is
activated.
Remote Sensor
Alarms Init Delay
10 - 9999 sec 180 sec
S220
High Remote
Temperature
34 - 210 °F
1.0 - 99.0 °C
90 °F
Sets the high/low remote sensor alarm thresholds.
Low Remote
Temperature
34 - 210 °F
1.0 - 99.0 °C
55 °F
S222 EEV Alarm Board
0 = NO
1 = NC
1 (NC)
S22A
Operation on
Sensor Failure
0 = Cooling
1 = Shutdown
0 (Cooling)
Selects function to occur if the temperature control sensor fails.
Full = Full, CFC Hold = hold last CFC
Operation on
Sensor Failure
Cooling Mode
0 = Full
1 = Hold
0 (Full)
Table B.2 Service Menu Alarm Settings by Line ID (continued)
