Vertiv Liebert iCOM - 13.6.3 U2 U Wiring Connections

Line
ID
Parameter
Name
Range
Default
Setting
Description
S224 -
S233,
S23A,
Customer Input 1 -
11
0 = Smoke
1 = Water Alarm
2 = C PMP Alarm
3 = Flow Alarm
4 = Stdby G Pump
5 = Stdby Unit
6 = C-Input 1
7 = C-Input 2
8 = C-Input 3
9 = C-Input 4
10 = Rht Lockout
11 = Hum Lockout
12 = Rht+Hum Lock
13 = Comp Lockout
14 = Call Service
15 = High Temp
16 = Air Loss
17 = FC Lockout
18 = Heater Alarm
19 = Flow AL SD
20 = Flow AL LC
1 (Water
Alarm) for
inputs 1-4
38 (Not Used)
for inputs 5-11
Selects the device and operation of the Customer Inputs. Each
event reflects a different alarm scenario and possible action to the
unit. A user may select whether the customer input is normally
open or normally closed. If the parameter is configured for Factory
STD., then it indicates that this input is factory configured and is
not configurable in the field.
S224 -
S233,
S23A,
(Cont'd)
Customer Input 1 -
11 (Cont'd)
21 = Comp Lock PD
22 = Enable FC
23 = HTRJ VFD
24 = HTRJ SPD
25 = Fire Alarm
26 = 2nd Setpoint
27 = Emergency Pwr
28 = LSI
29 = Cond 1 Fail
30 = Cond 2 Fail
31 = D-Scroll Red
32 = Swap Valve
33 = EC Fan Fault
34 = Eco Airflow
35 = Damper Switch
36 = Power A
37 = Power B
38 = Not Used
39 = Flow AL LFC
40 = Hand Mode
41 = Fan Overrd.
42 = Cool Overrd
1 (Water
Alarm) for
inputs 1-4
38 (Not Used)
for inputs 5-11
Selects the device and operation of the Customer Inputs. Each
event reflects a different alarm scenario and possible action to the
unit. A user may select whether the customer input is normally
open or normally closed. If the parameter is configured for Factory
STD., then it indicates that this input is factory-configured and is
not configurable in the field.
S224 -
S233,
S23A,
(Cont'd)
Customer Input
Active open/closed
Closed Open Closed
A user may select if the customer input is active when contacts
are open or closed.
S236
Event Delay Time
(sec)
10 - 9999 sec 10 sec
Main fan overload.Event Enabled Disabled Enabled Enabled
Event: MAIN FAN
OVERLOAD
MESSAGE WARNING ALARM ALARM
S237
Initial Loss of
10 - 600 sec 30 sec Loss of airflow.
