2-6 About the CLARiTY® Operating System Rev AA
Videojet DataFlex 6420 Operator Manual
Table 2-2 shows the buttons used to select a new job or view the current
job selected.
The navigation bar (Figure 2-4) indicates the location of the current page
in the menu tree. Use the navigation bar to do one of the following:
• Touch the Back button to go back to the previous page.
• Touch any title on the navigation bar to go to that page directly.
Buttons Display
Job Page (to load the next
image or job to be printed,
and to enter any variable
data)
Current Job (shown as the
Current Job Name)
Table 2-2: Buttons for Viewing Jobs
Figure 2-4: Navigation Bar
1
2
1. Back Button
2. Navigation Bar
