Vitosol 300-TM vacuum tube collectors, type SP3C
Vertical installation
A
C
D
B
A
Collector
B
Rafter anchor
C
Mounting rail
D
Tube retainer
Horizontal installation
50
A
C
D
B
A
Collector
B
Rafter anchor
C
Mounting rail
D
Tube retainer
Vitosol 200-TM vacuum tube collectors, type SPEA
Vertical installation
A
C
D
B
A
Collector
B
Rafter anchor
C
Mounting rail
D
Tube retainer
Design information regarding installation on pitched roofs — above roof installation
(cont.)
