Collector supports with fixed angle of inclination
Type SV and SH
a
A
C
A
B
A
Footplates
B
Adjustable support
C
Collector support
Ø 5.5
2x
Ø 11
2x
150
100
100
20
18
2430
Type SV SH
a mm 2580 1000
B
y
x
z
a
B
A
Example: Fixing for 3 collectors
A
Cross brace
B
On-site substructure, e.g. steel beams (on site)
Type SV SH
x in mm 1080 2400
z in mm See page 108. See page 108.
Design information regarding flat roof installation
(cont.)
